Description Model PLC-434P-AU-IR2/PR Image sensor 1 / 2.7 “CMOS Image Size 2560×1440 Electronic Shutter 1 s ~ 1 / 100000 s Iris Type Fixed Iris Min. Illumination 0.011 lux @F1.2, AGC ON; 0 lux with IR 0.04 lux @ F2.2, AGC ON; 0 lux with IR Lens 2.8 mm @F2.0, (fixed lens), horizontal field of view: °110 Focus Fixed Lens Mount M12 Wide Dynamic Range Digital WDR BLC Yes HLC Yes Defog Yes Digital NR 3D DNR Angle Adjustment Pan: 0°~360°; Tilt:0°~80°; Rotation: 0°~360° Video Compression H.265 / H.264 H.264 Compression Standard Main [email protected] High Tier Resolution 4MP (2560 × 1440), 3MP (2304 × 1296), 1080P (1920 × 1080), 720P (1280 × 720), D1, CIF, 480 × 240 Main Stream 60Hz: 4MP(1~20fps)/3MP(1~30fps)/1080P(1~30fps); 50Hz: 4MP(1~20fps)/3MP(1~25fps)/1080P(1~25fps) Sub Stream 60Hz: 720P(1~15fps)/D1 (1~30fps)/CIF (1~30fps); 50Hz: 720P(1~12fps)/D1(1~25fps)/CIF (1~25fps); Third Stream 60Hz: D1/CIF/480×240 (1~30fps); 50HZ: D1/CIF/480×240 (1~25fps) Audio Compression G711A/U Bit Rate 64 Kbps ~ 5 Mbps Bit Rate Type VBR / CBR Image Settings ROI, Saturation, Brightness, Hue, Contrast, Wide Dynamic, Sharpness, NR, etc. adjustable through client software or web browser ROI Each ROI to be configured separately Network RJ45 Video Output No Audio 1CH Built-in MIC Storage No Reset No Remote Monitoring Web browsing, CMS remote control Web Browser IE (plug-in required)/Google Chrome/Edge/Firefox/Safari Online Connection Support simultaneous monitoring for up to 4 users; Support multi-stream real time transmission Network Protocol UDP, IPv4, IPv6, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, FTP, 802.1x, UPnP, HTTP, HTTPs, QoS Interface Protocol ONVIF Storage Network remote storage Smart Alarm Motion detection Intelligent Analytics Region intrusion detection, video blur detection, scene change detection, line crossing detection General Function Watermark, IP address filtering, video mask, heartbeat, illegal login lock IR Distance 10 ~ 20m PoE Yes, IEEE802.3af IR Distance 10 ~ 20m Ingress Protection IP67 Power Supply DC12V/PoE Power Consumption < 4W Operating Conditions – 20 °C ~ 55 °C (-4°F~131°F) Humidity: less than 95 % (non-condensing) Dimensions (mm) 162.1 × 74.8 × 73.8 Weight (net) Approx. 0.24KG Installation Ceiling mounting; Wall mounting Certificate CE, FCC Environmental Protection Complies with Directive EU RoHS, WEEE (2012/19/EU), directive 94/62/EC and REACH(EC1907/2006)
