DescriptionJE Hall JCC3-55E Cellar Cooling J E Hall – J6LC56CV1 (condensing Unit) – JCC3-55E (Evaporator) Max cubic area Above Ground 115M3 Max cubic area below Ground 65M3 Maximum Pipe Run 25M If pipe run between 15M >25M use fan speed controller Maximum Pipe Rise 8M (Maximum Pipe Run must include Rise) Outside Noise Level 32 dB(A) 25 Amp single phase.Dimensions: JCC3-55E (Internal): Width – 904mm Depth – 370mm Height – 546mm. Unit Weight 36Kgs Packing weight 43kgs J5LC25C (External): Width – 855mm Depth – 328mm Height – 753mm. Unit Weight 50Kgs Packing Weight 54kgsBrewery specification 6 fins per inch evaporator coil Galvanised mild steel casing with polyester powder coating Electronic controller Low pressure safety switch Acoustic insulation on outdoor unit and compressor 3/4” BSP drain fitting on indoor unit The JE Hall JCC3-55E Cellar Cooling can operate down to 4°C and up to 16°C Therefore suitable for a wide range of applications from cellar cooling, wines, flowers, fruit & vegetables etc. Suitable for pipe runs up to 25 metres Unit does not come pre charged with R448/R449
