Sale!
CAMERAImage Sensor1/2.8” Progressive Scan CMOSShutter Speed1/3 to 1/10000 sSlow ShutterYesMinimum Illumination0.005 Lux; 0 Lux with IR/White LightDay/Night MechanismIR Cut FilterDay/Night SwitchUnified/ Scheduled/ AutoLENSTypeFixed Focal LensFocal Length2.8/4/6 mmApertureF1.6FOV• 2.8 mm: Horizontal FOV: 107.5°, Vertical FOV: 57.2°, Diagonal FOV: 128.7°• 4 mm: Horizontal FOV: 84.4°, Vertical FOV: 44.3°, Diagonal FOV: 100.6°• 6 mm: Horizontal FOV: 55.1°, Vertical FOV:30.2°, Diagonal FOV: 64°Lens MountM12DORI Distance• 2.8 mm: Detect: 52 m (170 ft) Observe: 22 m (71 ft) Recognize: 10 m (34 ft) Identify: 5 m (17 ft)• 4 mm: Detect: 70 m (230 ft) Observe: 29 m (96 ft) Recognize: 14 m (46 ft) Identify: 7 m (23 ft)• 6 mm: Detect: 100 m (327 ft) Observe: 41 m (136 ft) Recognize: 20 m (65 ft) Identify: 10 m (33 ft)Angle Adjustment (Manual)Range• Pan: 0° to 360° • Tilt: 0° to 90° • Rotation: 0° to 360°ILLUMINATORIR LED• Quantity: 2 • Range: 30m • Wavelength: 850nmWhite LED• Quantity: 2 • Range: 30mIlluminator On/Off ControlAuto/Scheduled/Always on/Always offVIDEOMax. Resolution2304 × 1296Main Stream• Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps • Resolution:2304×1296, 2048×1280, 1920×1080, 1280×720Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.Sub-Stream• Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps • Resolution:704×576, 640×480, 352×288, 320×240Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.Bit Rate ControlCBR, VBRVideo Compression• Main Stream: H.265 /H.265/H.264 /H.264 • Sub-Stream: H.265/H.264H.264 TypeHigh ProfileH.264 Main Stream SupportedH.265 TypeMain ProfileH.265 Main Stream SupportedVideo Bit Rate• Main Stream: 256 Kbps to 4 Mbps • Sub-Stream: 64 Kbps to 512 KbpsImageImage Settings• Mirror • Brightness • Contrast • Saturation • Sharpness • Exposure • WDR • White Balance • Prevent Overexposure to Infrared Light • HLC Adjustable by Client Software • Rotation(90°/270°)Image EnhancementBLC/3D DNR/HLC/SmartIRWide Dynamic RangeDWDRSNR≥ 52 dBImage Parameters SwitchYesPrivacy MaskUp to 4 MasksROI1 RegionOSD SettingYesAUDIOAudio CommunicationN/AAudio InputYesAudio OutputN/AAudio CompressionYesAudio Sampling Rate8KHzEnvironment Noise FilteringYesAudio Bit Rate64 Kbps(G.711 alaw)NETWORKProtocol• TCP/IP • UDP • ICMP • HTTP • HTTPS • DHCP, DNS, RTSP • NTP • UPnP • SSL/TLS • FTP/SFTP • RTP • IPv4 • IPv6 • ARPONVIFYesAPIOpen Network Video Interface (Profile S)Simultaneous Live View3 Main Streams & 3 Sub-StreamsClientVIGI App, VIGI Security Manager, Web UIWeb Browser• Google Chrome® 57 and above • Firefox® 52 and above • Safari® 11 and above • Microsoft® Edge 91 and aboveCloudYesSecurityPassword Protection, HTTPS Encryption, IP Address Filter, Digest AuthenticationALARM AND EVENT MANAGEMENTSmart Event• Intrusion Detection • Line-Crossing Detection • Region Entering Detection • Region Exiting Detection • Object Abandoned Detection • Object Removal Detection • Abnormal Sound Detection • People Detection • Vehicle DetectionBasic Event• Motion Detection (Enhanced with Human & Vehicle Classification for more accurate alerts) • Video Tampering Detection • Exception ( Illegal Login)Alarm Linkage• White Light Flashing • Message PushINTERFACESNetwork Interface1 RJ45 10/100M Self-Adaptive Ethernet Port, PoEAlarmN/AReset ButtonN/APowerDC Power PortOn-board StorageN/ABuilt-in MicrophoneYes; Records Anything Going on within a 15-ft Radius of the CameraBuilt-in SpeakerN/AAudioN/AGENERALOperating Temperature-30–60 °CStorage Temperature-40–60 °COperating Humidity95% or Less (Non-Condensing)Storage Humidity95% or Less (Non-Condensing)Package Content• VIGI Network Camera • Quick Start Guide • Waterproof Cable Attachments • Mounting AccessoriesMaterialPlasticNet Weight0.32 KgGross Weight0.48 KgPower Supply• 12V DC ± 5%, Max. 5.5 W, 5.5mm Coaxial Power Plug • PoE: 802.3af/at, class 0, Max. 6 WProtectionIP67 WaterproofProduct Dimensions (L x W x H)78.5 × 188.0 × 71.5 mm (3.09 × 7.40 × 2.81 in)CertificationsCE, NTRA, VCCI, BSMI รหัสสินค้า: VIGI C330(4mm) หมวดหมู่: IP Camera
